Go tool pprof使用方式

go中有pprof包来做代码的性能监控主要涉及两个pkg：

#web服务器:import (    "net/http"    _ "net/http/pprof")#一般应用程序(实际应用无web交互)import (    "net/http"    _ "runtime/pprof")复制代码

net/http/pprof中只是使用runtime/pprof包来进行封装了一下，并在http端口上暴露出来。

Go tool pprof辅助工具安装(图形工具graphviz为例)

Windows：
1.官方下载安装包:
下载Stable稳定版本(.msi)
2.配置PATH系统环境变量：
C:\Program Files (x86)\Graphviz2.38\bin

Linux(例：Centos)

方式1).添加repo依赖http://204.178.9.49/graphviz-rhel.repo

yum list available 'graphviz*'yum install 'graphviz*'  --skip-broken#备注：--skip-broken可选：跳过错误依赖，不加这个参数会提示安装包依赖错误，因为这里并不需要其它的安装包，所以跳过即可。复制代码

--skip-broken可选：跳过错误依赖，不加这个参数会提示安装包依赖错误，因为这里并不需要其它的安装包，所以跳过即可。

方式2).源码包编译安装 ./configure make make install

MacOS:
brew install graphviz

Go tool pprof常用基本调试基本命令(默认30s采集时间，可通过--seconds)

HTTP场景(参数可选:--text)：

Heap profile:

go tool pprof --text http://localhost:8080/debug/pprof/heap  复制代码

CPU profile:

go tool pprof --text http://localhost:8080/debug/pprof/profile  复制代码

Goroutine blocking profile:

go tool pprof --text http://localhost:8080/debug/pprof/block  复制代码

1.实时通过地址查看浏览器: 2.通过生成的profile文件分析;

选择指定的profile压缩gz文件(.gz),使用go tool pprof进入

go tool pprof http://localhost:8080/debug/pprof/profile#结束后直接进入交互：(pprof)  web(pprof)复制代码

如查看历史调试文件信息，通过指定的profile文件进入即可: go tool pprof [*.gz]

pprof交互基本命令：web 直接生成web浏览器可访问的svg图;

(其他命令自行摸索) Windows下自动生成.svg文件且调用默认浏览器访问;

MacOS下自动生成.gz文件，系统限制可根据提示文件路径通过手动访问查看;

【注意事项】： profile文件为空的问题, heap和block一般不受影响。执行交互web命令会报:

(pprof) webprofile is empty(pprof) 复制代码

产生原因： pprof内存分析器采取抽样的方式，它仅仅从一些内存分配的子集中收集信息。有可能对一个对象的采样与被采样对象的大小成比例。通过使用go test --memprofilerate标识，或者通过程序启动时的运行配置中的MemProfileRate变量来改变调整这个采样的比例。如果比例为1，则会导致全部申请的信息都会被收集，但是这样的话将会使得执行变慢。默认的采样比例是每512KB的内存申请就采样一次。

方法1).在进行调试时，指定运行参数，或运行代码中动态调整参数

go tool pprof --text http://localhost:8080/debug/pprof/profile复制代码

此命令将会打印耗费最多CPU时间的函数列表。这里有几种可用的输出形式，最实用的有 --text, --web 和 --list。运行 "go tool pprof" 来得到完整的列表。

【备注】：实际测试时，MacOS下基本是空的,需要指定参数。

方法2).设置环境变量(此方法极不推荐!)设置Go环境变量 GODEBUG="memprofilerate=1".

通过控制采样的比例和行为，可以达到性能调试粒度的控制！

附pprof 交互命令help说(部分命令需要第三方工具支持)：

(pprof) help  Commands:   cmd [n] [--cum] [focus_regex]* [-ignore_regex]*       Produce a text report with the top n entries.       Include samples matching focus_regex, and exclude ignore_regex.       Add --cum to sort using cumulative data.       Available commands:         callgrind    Outputs a graph in callgrind format         disasm       Output annotated assembly for functions matching regexp or address         dot          Outputs a graph in DOT format         eog          Visualize graph through eog         evince       Visualize graph through evince         gif          Outputs a graph image in GIF format         gv           Visualize graph through gv         list         Output annotated source for functions matching regexp         pdf          Outputs a graph in PDF format         peek         Output callers/callees of functions matching regexp         png          Outputs a graph image in PNG format         proto        Outputs the profile in compressed protobuf format         ps           Outputs a graph in PS format         raw          Outputs a text representation of the raw profile         svg          Outputs a graph in SVG format         tags         Outputs all tags in the profile         text         Outputs top entries in text form         top          Outputs top entries in text form         tree         Outputs a text rendering of call graph         web          Visualize graph through web browser         weblist      Output annotated source in HTML for functions matching regexp or address   peek func_regex       Display callers and callees of functions matching func_regex.    dot [n] [focus_regex]* [-ignore_regex]* [>file]       Produce an annotated callgraph with the top n entries.       Include samples matching focus_regex, and exclude ignore_regex.       For other outputs, replace dot with:       - Graphic formats: dot, svg, pdf, ps, gif, png (use > to name output file)       - Graph viewer:    gv, web, evince, eog    callgrind [n] [focus_regex]* [-ignore_regex]* [>file]       Produce a file in callgrind-compatible format.       Include samples matching focus_regex, and exclude ignore_regex.    weblist func_regex [-ignore_regex]*       Show annotated source with interspersed assembly in a web browser.    list func_regex [-ignore_regex]*       Print source for routines matching func_regex, and exclude ignore_regex.    disasm func_regex [-ignore_regex]*       Disassemble routines matching func_regex, and exclude ignore_regex.    tags tag_regex [-ignore_regex]*       List tags with key:value matching tag_regex and exclude ignore_regex.    quit/exit/^D         Exit pprof.    option=value       The following options can be set individually:           cum/flat:           Sort entries based on cumulative or flat data           call_tree:          Build context-sensitive call trees           nodecount:          Max number of entries to display           nodefraction:       Min frequency ratio of nodes to display           edgefraction:       Min frequency ratio of edges to display           focus/ignore:       Regexp to include/exclude samples by name/file           tagfocus/tagignore: Regexp or value range to filter samples by tag                               eg "1mb", "1mb:2mb", ":64kb"            functions:          Level of aggregation for sample data           files:           lines:           addresses:            unit:               Measurement unit to use on reports            Sample value selection by index:            sample_index:      Index of sample value to display            mean:              Average sample value over first value            Sample value selection by name:            alloc_space        for heap profiles            alloc_objects            inuse_space            inuse_objects             total_delay        for contention profiles            mean_delay            contentions    :   Clear focus/ignore/hide/tagfocus/tagignore(pprof)复制代码
